Mercotac Model 205 United Kingdom
Enapart, with a presence in 14 countries, sources products from around the world to offer you the best possible prices as a local reseller in the United Kingdom . To acquire the best quotation for your desired product, kindly contact us through e-mail or our contact form.
High-speed model available (205-H) Low-torque/low-temp. models available (205-L) Available with stainless steel ball bearing (205-SS) Mercotac model 205 is ideal for thermocouples, strain gages, eddy current test devices, and wind turbine blade sensors, & other two-wire applications,due to its compact size, reliable quality signal connection, low torque and low cost. Model 205 replaces the old model 590 for Leslie speakers and Hammond organs.
Installation Notes:
the up arrow should not point below horizontal
do not solder to or bend connector tabs
avoid lateral forces and mechanical loads (overly stiff or tight wires)
do not rigid mount both ends of connector
limit mounting eccentricity (runout / wobble) to .005" (.13mm)
provide overload protection within the circuit
avoid vibration and bumping motions
